Set Up AWS CloudFront CDN with Terraform

Configure AWS CloudFront distribution with S3 origin, custom domain, SSL certificate, and cache policies using Terraform.

LLuca Berton1 min read

Introduction

#

CloudFront is AWS's global content delivery network. It caches your content at edge locations worldwide, reducing latency for users regardless of their location. This guide covers setting up a complete CloudFront distribution with Terraform, including S3 origin, custom domain, SSL, and optimized cache policies.

S3 Bucket as Origin

#
resource "aws_s3_bucket" "website" {
  bucket = "my-website-${var.environment}"
}

resource "aws_s3_bucket_public_access_block" "website" {
  bucket = aws_s3_bucket.website.id

  block_public_acls       = true
  block_public_policy     = true
  ignore_public_acls      = true
  restrict_public_buckets = true
}

resource "aws_s3_bucket_versioning" "website" {
  bucket = aws_s3_bucket.website.id
  versioning_configuration {
    status = "Enabled"
  }
}

Origin Access Control

#
resource "aws_cloudfront_origin_access_control" "main" {
  name                              = "s3-oac"
  description                       = "OAC for S3 website"
  origin_access_control_origin_type = "s3"
  signing_behavior                  = "always"
  signing_protocol                  = "sigv4"
}

data "aws_iam_policy_document" "s3_policy" {
  statement {
    principals {
      type        = "Service"
      identifiers = ["cloudfront.amazonaws.com"]
    }
    actions   = ["s3:GetObject"]
    resources = ["${aws_s3_bucket.website.arn}/*"]
    condition {
      test     = "StringEquals"
      variable = "AWS:SourceArn"
      values   = [aws_cloudfront_distribution.main.arn]
    }
  }
}

resource "aws_s3_bucket_policy" "website" {
  bucket = aws_s3_bucket.website.id
  policy = data.aws_iam_policy_document.s3_policy.json
}

CloudFront Distribution

#
resource "aws_cloudfront_distribution" "main" {
  origin {
    domain_name              = aws_s3_bucket.website.bucket_regional_domain_name
    origin_id                = "S3Origin"
    origin_access_control_id = aws_cloudfront_origin_access_control.main.id
  }

  enabled             = true
  is_ipv6_enabled     = true
  default_root_object = "index.html"
  aliases             = [var.domain_name, "www.${var.domain_name}"]
  price_class         = "PriceClass_100"

  default_cache_behavior {
    allowed_methods  = ["GET", "HEAD", "OPTIONS"]
    cached_methods   = ["GET", "HEAD"]
    target_origin_id = "S3Origin"

    cache_policy_id          = aws_cloudfront_cache_policy.optimized.id
    origin_request_policy_id = aws_cloudfront_origin_request_policy.cors.id
    response_headers_policy_id = aws_cloudfront_response_headers_policy.security.id

    viewer_protocol_policy = "redirect-to-https"
    compress               = true
  }

  # Cache static assets longer
  ordered_cache_behavior {
    path_pattern     = "/assets/*"
    allowed_methods  = ["GET", "HEAD"]
    cached_methods   = ["GET", "HEAD"]
    target_origin_id = "S3Origin"

    cache_policy_id        = aws_cloudfront_cache_policy.static_assets.id
    viewer_protocol_policy = "redirect-to-https"
    compress               = true
  }

  custom_error_response {
    error_code            = 404
    response_code         = 200
    response_page_path    = "/index.html"
    error_caching_min_ttl = 10
  }

  restrictions {
    geo_restriction {
      restriction_type = "none"
    }
  }

  viewer_certificate {
    acm_certificate_arn      = aws_acm_certificate.main.arn
    ssl_support_method       = "sni-only"
    minimum_protocol_version = "TLSv1.2_2021"
  }

  tags = {
    Environment = var.environment
    ManagedBy   = "terraform"
  }
}

Cache Policies

#
resource "aws_cloudfront_cache_policy" "optimized" {
  name        = "optimized-caching"
  default_ttl = 86400
  max_ttl     = 31536000
  min_ttl     = 0

  parameters_in_cache_key_and_forwarded_to_origin {
    cookies_config {
      cookie_behavior = "none"
    }
    headers_config {
      header_behavior = "none"
    }
    query_strings_config {
      query_string_behavior = "none"
    }
    enable_accept_encoding_brotli = true
    enable_accept_encoding_gzip   = true
  }
}

resource "aws_cloudfront_cache_policy" "static_assets" {
  name        = "static-assets"
  default_ttl = 604800
  max_ttl     = 31536000
  min_ttl     = 604800

  parameters_in_cache_key_and_forwarded_to_origin {
    cookies_config {
      cookie_behavior = "none"
    }
    headers_config {
      header_behavior = "none"
    }
    query_strings_config {
      query_string_behavior = "none"
    }
    enable_accept_encoding_brotli = true
    enable_accept_encoding_gzip   = true
  }
}

Security Headers

#
resource "aws_cloudfront_response_headers_policy" "security" {
  name = "security-headers"

  security_headers_config {
    strict_transport_security {
      access_control_max_age_sec = 63072000
      include_subdomains         = true
      preload                    = true
      override                   = true
    }

    content_type_options {
      override = true
    }

    frame_options {
      frame_option = "DENY"
      override     = true
    }

    xss_protection {
      mode_block = true
      protection = true
      override   = true
    }

    referrer_policy {
      referrer_policy = "strict-origin-when-cross-origin"
      override        = true
    }
  }
}

SSL Certificate

#
resource "aws_acm_certificate" "main" {
  provider          = aws.us_east_1  # CloudFront requires us-east-1
  domain_name       = var.domain_name
  subject_alternative_names = ["*.${var.domain_name}"]
  validation_method = "DNS"

  lifecycle {
    create_before_destroy = true
  }
}

Best Practices

#
  1. Use Origin Access Control (OAC) instead of Origin Access Identity (OAI)
  2. Enable Brotli and Gzip compression for smaller payloads
  3. Set appropriate cache TTLs — longer for static assets, shorter for HTML
  4. Use PriceClass_100 for cost savings if your users are mainly in US/EU
  5. Add security headers via response headers policy
  6. Enable versioning on S3 for rollback capability
  7. Use CloudFront Functions for URL rewrites instead of Lambda@Edge for simple logic

Hands-On Courses

#

Learn by doing with interactive courses on CopyPasteLearn:

Conclusion

#

CloudFront with Terraform provides a scalable, secure CDN setup that's fully reproducible. By combining S3, OAC, custom cache policies, and security headers, you get a production-ready content delivery infrastructure that serves your users from the nearest edge location with optimal performance and security.
