Fix Terraform Error - Error Creating Subnet - InvalidSubnet Conflict

Fix InvalidSubnet and CIDR conflict errors when creating VPC subnets in Terraform. Handle overlapping CIDRs, AZ limits, and subnet quota issues.

LLuca Berton1 min read

Quick Answer

#

The subnet CIDR overlaps with an existing subnet in the VPC, or the CIDR is outside the VPC range. Use cidrsubnet() to calculate non-overlapping CIDRs automatically, and check existing subnets with aws ec2 describe-subnets.

The Error

#
Error creating Subnet: InvalidSubnet.Conflict:
The CIDR '10.0.1.0/24' conflicts with another subnet
Error creating Subnet: InvalidSubnet.Range:
The CIDR '10.1.0.0/24' is not within the VPC CIDR of '10.0.0.0/16'

What Causes This

#
  • CIDR overlap — two subnets with the same or overlapping IP range
  • CIDR outside VPC — subnet CIDR doesn't fall within VPC CIDR block
  • Manually created subnet — someone made a subnet in the console with the same CIDR
  • Previous apply partially failed — subnet exists in AWS but not in state

How to Fix It

#

Solution 1: Use cidrsubnet() for Automatic Calculation

#
resource "aws_vpc" "main" {
  cidr_block = "10.0.0.0/16"
}

resource "aws_subnet" "public" {
  count             = 3
  vpc_id            = aws_vpc.main.id
  cidr_block        = cidrsubnet(aws_vpc.main.cidr_block, 8, count.index)
  # 10.0.0.0/24, 10.0.1.0/24, 10.0.2.0/24
  availability_zone = data.aws_availability_zones.available.names[count.index]
}

resource "aws_subnet" "private" {
  count             = 3
  vpc_id            = aws_vpc.main.id
  cidr_block        = cidrsubnet(aws_vpc.main.cidr_block, 8, count.index + 10)
  # 10.0.10.0/24, 10.0.11.0/24, 10.0.12.0/24 — no overlap
  availability_zone = data.aws_availability_zones.available.names[count.index]
}

Solution 2: Check Existing Subnets

#
# List all subnets in the VPC
aws ec2 describe-subnets \
  --filters "Name=vpc-id,Values=vpc-abc123" \
  --query 'Subnets[*].[SubnetId,CidrBlock,AvailabilityZone]' \
  --output table

Solution 3: Import the Existing Subnet

#
terraform import aws_subnet.public[0] subnet-abc123

CIDR Planning Example

#
VPC: 10.0.0.0/16 (65,536 IPs)
├── Public Subnets
│   ├── 10.0.0.0/24  (AZ a) — 256 IPs
│   ├── 10.0.1.0/24  (AZ b)
│   └── 10.0.2.0/24  (AZ c)
├── Private Subnets
│   ├── 10.0.10.0/24 (AZ a)
│   ├── 10.0.11.0/24 (AZ b)
│   └── 10.0.12.0/24 (AZ c)
└── Database Subnets
    ├── 10.0.20.0/24 (AZ a)
    ├── 10.0.21.0/24 (AZ b)
    └── 10.0.22.0/24 (AZ c)

Troubleshooting Checklist

#
  1. ✅ Does the CIDR fall within the VPC CIDR?
  2. ✅ Does it overlap with any existing subnet?
  3. ✅ Was the subnet created manually in AWS?
  4. ✅ Are you using cidrsubnet() to avoid math errors?
#

Conclusion

#

Subnet CIDR conflicts happen when ranges overlap or fall outside the VPC. Use cidrsubnet() to calculate non-overlapping ranges automatically, offset private subnets from public ones, and check existing subnets before adding new ones.
